Terex Manlift Specifications
Terex is a Westport, Connecticut company that specializes in making in manufacturing construction equipment. machinery such as boom lifts, aerial lifts and manlifts. These equipments are designed to facilitate access to areas that are difficult to reach, large equipment, roofs and buildings, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration refers to a power-driven endless belt. This belt moves only in one direction and includes steps or handholds or paltforms that are connected to the unit in order to transport personnel from each floor.
TB85
Terex's TB85 man lift provides a max working height at 91 feet. The platform's max height reaches 85 feet, whilst the maximum width of the model is 8.5 feet. The TB85 has dimensions which measure 9 feet, 1-inch high and 9 inches wide by 36 feet. This particular model provides a reach of seventy feet. The TB85 has a boom angle below horizontal measures at -14 degrees and above horizontal reaching 75 degrees.
Terex TB100
The maximum working height of the Terex TB100 is 106 feet and the platform's maximum height is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The TB110 has a maximum platform height of 100 feet and the unit's maximum working height overall reaches 116 feet. When stowed, this model is 8 feet wide x 9 feet, 4 inches high. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This particular model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. Below horizontal it is -14 degrees and it measures -105 degrees articulating.
